Unity of Powers!

With the comfort provided by less recoil advantage of gas-operated systems and the ability to shoot any load from lighter 24 gr. (7/8 oz.) up to 50 gr. (1 ¾ oz.) heavy magnum loads through the active valve system, and now, together with the proven rotating locking head bolt, the new HYBRID Series is here!

In addition to all these technical specifications and in combination with familiar Akdas quality, we have created a shotgun that suits any shooter or hunter seeking everything on a single gun.

The recoil spring is housed in the forend, which increases the strength of the stock and allows a more elegant grip design. Various options, such as composite plastic stocks and camouflage coating, will help you deal with hard hunting conditions.

20 Ga version is also available.

Details

  • Model

    AH-200W

  • Kalibre

    12 ga (AH-212W), 20 ga (AH-220W)

  • Sistem

    Gas Operated with Rotating Bolt Head (Active Valve)

  • Şarjör Kapasitesi

    3+1

  • Şoklar

    MCH (F*, IM**, M***, IC****, C*****)

  • Ağırlık

    3,0 – 3,4 kg (6.6 – 7.5 lb.)

  • Gövde

    7075-T6 Aluminum Alloy

  • Gövde Kaplaması

    Anodized

  • Mekanizma Parçaları

    AISI 4140 Carbon Steel

  • Namlu Boyu

    61 cm, 66 cm, 71cm (26”, 28”, 30”)

  • Namlu

    AISI 4140 Carbon Steel

  • Namlu Kaplaması

    Gloss Chrome

  • Arpacık

    Brass Bead

  • Üst Bant

    7 mm Silver Soldered

  • Kundak

    Turkish Walnut

  • Kundak Ön/Arka Düşüklüğü

    1.45” (37 mm) / 2 .25” (57 mm)

  • Tetik Çekme Mesafesi

    360, 370 mm (14.20”, 14.5”)

  • Fişek Yatağı

    76 mm (3”)

  • Emniyet

    Manual

  • Tetik Ağırlığı

    2,2 – 2,5 kg (4.8 – 5.5 lb.)

  • Toplam Uzunluk

    121 cm (47.5” - 66 cm/26” barrel)

  • Optional

    Left Ejection Port (12 ga)

  • Optional

    Fiber Optic

  • Optional

    Cerakote Receiver Finish

  • Stock Shims

    +5 : 39/61 mm (1.53”/2.40”) -5 : 35/51 mm (1.37”/2”) -10: 33/47 mm (1.29”/1.85”) -15: 32/43 mm (1.25”/1.69”)
